Aluminium Bi-Fold Doors from Origin Global: 20 Year Guarantee

Homeowners
Business

Versatile, aesthetically pleasing and practical…

Unlike any other door, our bi-folds provide a completely uninterrupted view when open, and the flexibility to enjoy your indoor and outdoor space as one.

Click on the roundels below to find out more about the shared benefits of all Origin products…

Find out more about the shared benefits of Origin products…

Choose one…

Large expanses of glass, slim profile…

Complementing the rest of the Origin range, our bi-fold doors create a harmonious look with existing door and window systems – right down to the slim profiles. The large expanses of glass sit within an ultra-strong aluminium profile, and you can choose the OB-49 or the OB-72, both with their own individual characteristics to suit different styles.

OB-49

OB-72

Comparing the OB-49 and the OB-72…

The key difference between the OB-49 and the OB-72 are the sightlines they achieve. In the table below, we run into the performance and differences between the two.

Compare the differences

	OB-49	OB-72
Sightline * Sizes denote glass to glass measurements.	OB-49 110mm *	OB-72 154mm *
Sizes - Height (differs with threshold used)	OB-49 Min. 524mm - Max. 3000mm	OB-72 Min. 524mm - Max. 3000mm
Sizes - Width	OB-49 Min. 463mm - Max. 27600mm With joining tracks	OB-72 Min. 474mm - Max. 27600mm With joining tracks
Popular Colours	OB-49 7015M, 7016M, 7021M, 9005M, 9007M, 9910G, 9910M and 9910G/7016M (dual colour)	OB-72 7015M, 7016M, 7021M, 9005M, 9007M, 9910G, 9910M, 9910G/7016M (dual colour), Golden Oak and Natural Oak
Dual Colour Option	OB-49	OB-72
Midrail Option	OB-49	OB-72
Glazing Bar Option	OB-49 No - But flat trim can be used to create the same effect	OB-72
Lead Times Lead times displayed may change without prior notice and will depend on installation availability.	OB-49 & OB-72 Popular colours - Your Lead Time, Not Ours (available in as little as 24-hours) RAL colours - 3 Weeks
U-Value	OB-49 Up to 1.2W/m²K	OB-72 Up to 1.3W/m²K
Security	OB-49 Unique 8-point locking system with 3-Star Diamond cylinder and PAS 24:2016 as standard	OB-72 Unique 8-point locking system and upgradeable to a 3-Star Diamond cylinder and PAS 24:2016
Secured By Design	OB-49	OB-72
Guarantee Lengths	OB-49 & OB-72 Standard - Up to 20 years Marine Environment - 10 years (frame) & 5 years (hardware)

Close the table

Made for you…

Whether you have a period home, new build, unconventional property or quaint cottage, there’s a bi-fold which will complement your home and allow you to enjoy it in a completely new way.

Created bespoke to ensure you can make the most of your space, Origin bi-folds range from one to eight door sets and individual doors can be manufactured as narrow as 400mm, as wide as 1200mm and as tall as 3000mm. You can choose how they open and close – whether they fold in or out, and how they slide – to meet your exact needs.

Overall size
System
Number of doors
Configuration
One or dual colour
Threshold option
Accessory finishes
Open in or out
Handle model

A seamless link, your way…

Creating that truly seamless link between your home and outside space is all in the threshold. We recommend a weathered threshold, which can be sunk into the floor. It leaves a minimal lip but provides a protective weathertight seal.

Non-weathered options offer a level floor finish and create a seamless transition between the inside and out. Non-weathered options are largely recommended for internal usage.

Opt for a classic Georgian look…

When you think of bi-fold doors, you may envision wide expanses of glass with light flooding in without much variation, but it is possible to personalise your bi-folds to ensure they truly complement your home and your style.

Taking a traditional design and making it cool and contemporary, you can opt for Georgian bars. By placing bars vertically, horizontally or both, our crittall-style or steel-framed doors create a classic style and an extra sense of cosiness while still allowing for vast expanses of light.

Doors that glide effortlessly…

An intelligently engineered short wheelbase carriage assembly with four wheels, manufactured from a high-grade acetal, guides the doors along the track seamlessly, enabling them to open and close with ease. It’s quality you can see, feel and admire.

Colour-coded trolley

Wheelbase carriage assembly with four wheels

Handled with care…

Get the right finishing touch for your Origin bi-fold door

Premium stainless-steel handles

Stainless steel handle range which can also be colour coded

Solid stainless steel lever handle with separate escutcheon (Style 253/280)

Solid stainless steel lever handle with separate escutcheon (Style 251/280)

Solid stainless steel lever handle with separate escutcheon (Style 301/280)

Solid stainless steel lever handle with separate escutcheon (Style 303/280)

Solid stainless steel lever handle with long back plate (Style 253/270)

Slave and D-handles are availabe in any of the 150 RAL shades or can be specified in a stainless steel finish. These are used across both the OB-49 and OB-72

Handle your door your way…

Our aluminium lever handle comes as standard on the OB-72 and is available in three colour options

White aluminium lever handle

Chrome aluminium lever handle

Black aluminium lever handle

Configurations…

Choosing your Origin Door has never been easier. If you know your rough opening size, find the nearest opening measurement in the table below and scan down the column to view your possible door options.

Configurations are available up to twelve doors. Above sizes are for guidance only and subject to glass specification

Optimum door sizesWide door leaf sizesNarrow door leaf sizes

Explore our door configurations…

Explore a list of recommended and popular configurations for our Bi-Fold Doors

Explore the configurations

1 Door1+0

1 Door1+0 With Midrail

2 Door2+0

2 Door1+1

3 Door2+1

3 Door3+0

4 Door1+1 With Sidelights

4 Door1+3

4 Door4+0

5 Door2+3

5 Door4+1

5 Door5+0

6 Door3+3

6 Door5+1

7 Door1+6

7 Door3+4

7 Door5+2

7 Door7+0

8 Door1+7

8 Door3+5

8 Door8+0

9 Door1+8

9 Door2+7

9 Door4+5

9 Door9+0

10 Door3+7

10 Door5+5

10 Door7+3

10 Door9+1

10 Door10+0

12 Door7+5

Close the configurations
