Delivering first-in-class design, our sliding door range provides the most spectacular finish for any building project. Available in four different sightlines across two different sliding door systems – the Origin Artisan Slider and the Origin Patio Slider – we have some of the slimmest sliding doors on the market, allowing for some of the largest glass expanses to be achieved to offer maximum, uninterrupted views whilst not compromising on quality or thermal performance. Both systems are modern, architecturally striking variations on the traditional patio door system.
Click on the roundels below to find out more about the shared benefits of all Origin products…
Made your way…
Completely bespoke and tailored to your requirements, you can customise your door down to every last detail. Working with us and your chosen Origin Partner, we’ll guide you through the personalisation process.
System type- Overall size
Configuration
Colour
Handle style and colour
Comparing the Artisan and Patio Sliding Doors…
The key differences between the Artisan Slider OS-20 and the Patio Slider OS-29 / OS-44 / OS-77
| OS-20 | OS-29 | OS-44 | OS-77 | |
|---|---|---|---|---|
| Interlocker Sightline Sizes denote glass to glass measurements | OS-20 20mm | OS-29 29mm | OS-44 44mm | OS-77 77mm |
| Sizes - Height (overall size) | OS-20 Min. 1600mm Max. 3000mm | OS-29 Min. 2005mm Max. 2600mm | OS-44 Min. 1940mm Max. 2600mm | OS-77 Min. 1940mm Max. 2600mm |
| Sizes - Width (overall size) | OS-20 Min. 1228mm Max. 13196mm | OS-29 Min. 1463mm Max. 11929mm | OS-44 Min. 1463mm Max. 11803mm | OS-77 Min. 1462mm Max. 11803mm |
| Popular Colours | OS-20 7016M, Anodised Silver | OS-29 7015M, 7016M, 7021M, 9005M, 9007M, 9910G, 9910M | OS-44 7015M, 7016M, 7021M, 9005M, 9007M, 9910G, 9910M | OS-77 7015M, 7016M, 7021M, 9005M, 9007M, 9910G, 9910M |
| Lead Times Lead times displayed may change without prior notice and will depend on installation availability. | OS-20 Any RAL Colour – 4‑Weeks Anodised Silver – 6‑Weeks | OS-29 Popular Colours - 2‑weeks Special RAL Colours – 4‑Weeks | OS-44 Popular Colours - 1‑week Special RAL Colours – 4‑Weeks | OS-77 Popular Colours - 1‑weeks Special RAL Colours – 4‑Weeks |
| We are currently working to temporary lead times. See the most up-to-date delivery times | ||||
| Glazing Options | OS-20 Wet glazing (glass units are bonded to the frame using structural sealant) | OS-29 Semi-dry glazing (glass units are bonded to the frame on site) | OS-44 Dry glazing (glass units are fixed to the frame using gaskets) | OS-77 Dry glazing (glass units are fixed to the frame using gaskets) |
| U-Value | OS-20 1.4W/m2K | OS-29 Up to 1.2W/m2K | OS-44 Up to 1.2W/m2K | OS-77 Up to 1.2W/m2K |
| Guarantee | OS-20 Standard - Up to 10 years frames and hardware, 5 years on glass
| OS-29 Standard - Up to 20-years
Marine Environment – 10‑years (frame) & 5‑years (hardware) | OS-44 Standard - Up to 20-years
Marine Environment – 10‑years (frame) & 5‑years (hardware) | OS-77 Standard - Up to 20‑years
Marine Environment – 10‑years (frame) & 5‑years (hardware) |
Open up your world with a glide…
Effortlessly open up your home as your door glides along the specially designed track, which allows the doors to pass each other smoothly – today, tomorrow, and even after years of use.
Double and triple tracks are available, and these will be determined by your chosen configuration. The beauty of a slider is that you choose where your opening is, whether that’s to the left, right, or the middle of your space.
Each track is concealed – this means there’s less chance of anyone catching their fingers or toes as they explore your inside and outside worlds. It’s also possible to take the integrated look even further by recessing the track into the floor, for an ultra-sleek flush finish.
In terms of operation, weighted bearings also stop the doors from moving once they’re in place, for an extra level of safety, and the doors also feature a stop function which stops the lead door from overrunning in its track.
Configurations…
Whether you’re planning a replacement, renovation or a new-build, we have a range of configurations available to suit your desired aperture. Using our size guide below, you can estimate approximately how many doors you can accommodate in your project.
Narrow panelsOptimum panelsWide panels
Popular Configurations…
Key:O - indicates fixed sashX - Indicates opening sashIndicates opening direction
OX (1 fixed, 1 sliding) or XX (2 sliding)
OXX (1 fixed, 2 sliding) or XXX (3 sliding)
OXXO (2 fixed, 2 sliding). XXXX (4 sliding) configuration is also available exclusively on the OS-20
OXXXXO (2 fixed, 4 sliding) - XXXXXX (6 sliding) configuration is also available exclusively on the OS-20
